Skip to contentHeat-shrinkable Tubings
- Eight harmful elements, halogen elements pass SGS testing
- Does not contain organotin compounds (tributyltin/tributyl tin), Asbestos (Asbestos), Smoke Agents (azocompounds) and substances released during the restriction period-formaldehyde
- Scope of application: -55℃~125℃
- Starting shrinkage temperature of 70 ℃, ultra-thin complete shrinkage temperature of 110 ℃, ordinary complete shrinkage temperature of 120 ℃, axial shrinkage ≤ 5%;Soft, flame retardant
- Complete specifications, φ0.6~φ180, and can be customized special specifications
- 2:1 clear heat shrink wrap is easy to use, with oven and hot air heating can shrink
| Part No. | As supplied | After recovery | Packing (L) |
| I.D. | Wall thickness(t) | Max .I.D. (I) | Wall thickness(T) |
| HC-0.8 | 1.1±0.2 | 0.15±0.03 | ≤0.50 | 0.30±0.10 | 200m/spool |
| HC-1.0 | 1.5±0.2 | 0.18±0.03 | ≤0.65 | 0.36±0.10 | 200m/spool |
| HC-1.5 | 2.0±0.3 | 0.18±0.03 | ≤0.85 | 0.36±0.10 | 200m/spool |
| HC-2.0 | 2.5±0.3 | 0.20±0.05 | ≤1.0 | 0.40±0.10 | 200m/spool |
| HC-2.5 | 3.0±0.3 | 0.20±0.04 | ≤1.25 | 0.40±0.10 | 200m/spool |
| HC-3.0 | 3.5±0.4 | 0.20±0.04 | ≤1.5 | 0.40±0.10 | 200m/spool |
| HC-3.5 | 4.0±04 | 0.22±0.04 | ≤1.75 | 0.44±0.10 | 200m/spool |
| HC-4.0 | 4.5±0.4 | 0.25±0.04 | ≤2.0 | 0.50±0.10 | 200m/spool |
| HC-4.5 | 5.0±0.4 | 0.25±0.04 | ≤2.25 | 0.50±0.10 | 100m/spool |
| HC-5.0 | 5.5±0.4 | 0.25±0.04 | ≤2.5 | 0.50±0.10 | 100m/spool |
| HC-5.5 | 6.0±0.4 | 0.25±0.04 | ≤2.75 | 0.50±0.10 | 100m/spool |
| HC-6.0 | 6.5±0.4 | 0.28±0.04 | ≤3.0 | 0.55±0.10 | 100m/spool |
| HC-6.5 | 7.0±0.3 | 0.28±0.04 | ≤3.25 | 0.55±0.10 | 100m/spool |
| HC-7.0 | 7.5±0.3 | 0.28±0.04 | ≤3.5 | 0.55±0.10 | 100m/spool |
| HC-8.0 | 8.5±0.5 | 0.28±0.04 | ≤4.0 | 0.60±0.10 | 100m/spool |
| HC-9.0 | 9.5±0.5 | 0.30±0.05 | ≤4.5 | 0.60±0.10 | 100m/spool |
| HC-10 | 10.5±0.5 | 0.30±0.05 | ≤5.0 | 0.60±0.10 | 100m/spool |
| HC-11 | 11.5±0.5 | 0.30±0.05 | ≤5.5 | 0.60±0.10 | 100m/spool |
| HC-12 | 12.5±0.5 | 0.30±0.05 | ≤6 | 0.60±0.10 | 100m/spool |
| HC-13 | 13.5±0.5 | 0.35±0.06 | ≤6.5 | 0.70±0.10 | 100m/spool |
| HC-14 | 14.5±0.5 | 0.35±0.06 | ≤7 | 0.70±0.10 | 100m/spool |
| HC-15 | 15.5±0.5 | 0.40±0.08 | ≤7.5 | 0.75±0.10 | 100m/spool |
| HC-16 | 16.5±0.5 | 0.40±0.08 | ≤8 | 0.75±0.10 | 100m/spool |
| HC-17 | 17.5±0.5 | 0.40±0.08 | ≤8.5 | 0.75±0.10 | 100m/spool |
| HC-18 | 19±0.7 | 0.40±0.08 | ≤9 | 0.75±0.10 | 100m/spool |
| HC-20 | 21±0.7 | 0.40±0.08 | ≤10 | 0.75±0.10 | 100m/spool |
| HC-22 | 23±0.7 | 0.40±0.08 | ≤11 | 0.80±0.15 | 100m/spool |
| HC-25 | 26±0.7 | 0.50±0.10 | ≤12.5 | 0.90±0.15 | 50m/spool |
